GENERAL SEAMING / BOTTOM HEMMING
Choose model
Choose Model
SPECIFICATION
| ① Model | ④ Function | ⑦ Needle gauge |
| ② Series | ⑤ Needle Plate Finger | ⑧ Device |
| ③ Covering Types | ⑥ Needle Numbers | ⑨Motor U：U Series H：H Series |
|
|
|
|
|
|
|
| |
|---|---|---|---|---|---|---|---|---|
| F007K(D )-W121-⑥⑦/FHA/(⑨) | 2 | 4 | 4.0/4.8 | 1.6~4.2 | 0.5~1.3 | 5 | H / U | 6000 |
| F007K(D )-W121-⑥⑦/FHA/(⑨) | 3 | 5 | 5.6/6.4 | 1.6~4.2 | 0.5~1.3 | 5 | H / U | 6000 |
| F007K(D)-W122-⑥⑦/FHA/(⑨) | 2 | 4 | 4.0/4.8 | 1.6~4.2 | 0.5~1.3 | 5 | H / U | 6000 |
| F007K(D)-W122-⑥⑦/FHA/(⑨) | 3 | 5 | 5.6/6.4 | 1.6~4.2 | 0.5~1.3 | 5 | H / U | 6000 |
| F007K(D)-W123-⑥⑦/FHA/(⑨) | 2 | 4 | 4.0/4.8 | 1.6~4.2 | 0.5~1.3 | 5/7 | H / U | 6000 |
| F007K(D)-W123-⑥⑦/FHA/(⑨) | 3 | 5 | 5.6/6.4 | 1.6~4.2 | 0.5~1.3 | 5/7 | H / U | 6000 |
| F007K(D)-W162-⑥⑦/FHA/(⑨) | 3 | 5 | 5.6/6.4 | 1.6~4.2 | 0.5~1.3 | 5/7 | H / U | 6000 |
| F007K(D)-W162H-⑥⑦/FHA/(⑨) | 3 | 5 | 5.6/6.4 | 6 | 0.5~1.3 | 5/7 | H / U | 6000 |
⑥
⑦
⑨
GENERAL SEAMING / BOTTOM HEMMING
Basic model of interlock stitch machine with double side coverstitching.
It is available for various sewing by optional devices.
Such as plain seaming and bottom hemming for underwears,
sportswears, etc… (equipped with adjustable hemming set)
W121 : Light material
W122 : Medium material
W123 : Heavy material
W162 : High needle bar stroke
W162H : High needle bar stroke
Long stitch length (6mm)
OPTIONAL DEVICE | |||
UTG ,UTH ,UTJ ,UTK,FL |
