ASO-ABF100J(B)

Automatic Button Feeder

Choose model

Choose Model

Model

ASO-ABF100J(B)

Sewing Way

Single Needle Lockstitch

Collocation Machine Head

SIRUBA LKS-1903AN / JUKI LK-1903A , LK-1903B , LK-1903AN / BROTHER BE438FX

Sewing Way

Single Needle Lockstitch

Stitch Length(P)

2.2/2.4/2.6/2.8/3.2/3.6 Standard

Button

Type: Round Flat Button (2 holes, 4 holes)

Button

Size :Ø8∼26mm ※Ø10mm is special specification, need to replace standard parts.

Thickness Of Button

1.5∼3.5mm

Ascending Rate Of Clamp

Maximum:13mm

Air Consumption

30L/min

Air Pressure

0.5 Mpa

Voltage

Single Phase AC200~240V 50/60Hz

Dimensions

(W)440×(D)560×(H)280mm

Production Capacity

Output: 2.2 sec/Button,13090 Buttons/8hr

All sewing image and
parameters are clearly
shown.

Button capable of supply,
and replacement. Easy
selection design.

Auto button size detection
and width adjustment by
stepping motor.

Modularized feeding
clamp, for different
button size and clamp
change.

SPECIFICATION OF BUTTON

Codes of PartsX+0.05
  -0.05
D+0.05
  -0.05
Button
Holes
ABF1182.21.04
ABF1192.21.02
ABF1202.41.24
ABF1212.41.22
ABF1222.81.24
ABF1232.81.22
ABF1243.21.24
ABF1253.21.22
ABF1263.61.24
ABF1273.61.22
ABF2692.61.24
ABF2702.61.22
ASO-ABF100J.100B-07

BUTTON SHAPE

Available Shape of Button
Two sides must be have obvious differences to make sure that the machine can differentiate the front & reverse side of the buttons.The convex / concave must above 1.2mm height difference.
Unavailable Shape of Button
The machine can’t identify the button when both sides are similar without obvious
differences.
