INTERLOCK
Needle Plate for Highly Elastic Fabrics
| applicable model | ITEM | |
|---|---|---|
| F007K(D)-W122-356 | E1836EF |  |
| C007L-W121(W122)-356 C007L-U121(U122)-356 C007L-W121(W122)-356/RH/RCH-3M C007L-U121(U122)-356/RH/RCH-3M C007KP-W122-356/CH C007KP-W122-356/CH-4M | E5356EF |  |
| C007L-W811A(W812A、W813A)-356/CRL C007KP-W811A(W812A、W813A)-356/CRL | E0226QF |  |
| S007K(D)-W121-356/PCH-3M S007K(D)-W122-356/PCH-3M | E3996EF |  |
| S007K-W812A-356/SRL | E3996RF |  |
CAR / SAR
Pneumatic Condense Stitching Device
CMR
Manual Condense Stitching Device
By reducing the strokes of feed dog, at the beginning and the end of sewing, condense stitching reinforces the stitches.This enhances the sewing sturdiness and quality. Basic model is controlled by pedal. Electric and pneumatic controls are optional.Exclusive gauge sets is required.
| Applicable Model | CAR ( Pneumatic ) | SAR ( Pneumatic ) | CMR ( Manual ) |
|---|---|---|---|
| C007KP / C007KP/DC□ | V | X | V |
| S007K / S007K/DS□ | X | V | X |
Self-installation : Y
CAF
OVERLOCK- SEAM COVERING (FOLD-DOWN TYPE)
1.Pneumatic Presser Foot Pressure Regulator uses the pneumatic device to keep the presser
foot pressure under uniform and minimal control. It can be adjusted to the suitable presser
foot pressure in real time regardless of the elasticity or extremely thin fabric under stable
holding pressure.
2.The pressure regulating valve is easy to operate, instantly visually detect the current
pressure of the presser foot and adjust it flexibly, shortening the adjustment time and
improving production efficiency.
*Note: 1. Air pressure equipment is required 2. Used with servo motor
Available Model:
All Interlock Series
Self-installation : N
CC
OVERLOCK- SEAM COVERING (FOLD-DOWN TYPE)
- Overturned seam covering for medium to heavy fabric after 4 thread plain seaming.
- Suitable for neck openings, sleeve, cuff or bottom of sportswear, T-shirt,etc… With fabric guide and special presser foot making sewing easy and more efficient.
Available Model:
C007KP-W322, C007L-W322
Self-installation : Y
CE
Overlock-Seam Covering (Fold-down / Flattening Type)
- 1. Bulging seam covering for medium fabric after 3 thread plain seaming.
- Suitable for neck openings, sleeve, cuff or bottom of sportswears, T-shirts, etc… With fabric guide and special presser foot making sewing easy and more efficient.
Available Model:
C007KP-W322, C007L-W322, C007L-U322
Self-installation : Y
CFC
Elastic Hemming
Elastic hemming evenly length and elasticity is controlled by gear box. Great for seam covering with two or three plies hemming binder on elastic for waistband or leg opening of briefs and shorts’s, etc…
Available Model:
C007KP-W542
Self-installation : Y
CH
HEMMING
Suitable for the bottom hemming of T-shirt, underwear, cuff of children’s garment,etc… Able to adjust the width of hemming set to fit demands, esay operation.
Available Model:
C007KP-W121, C007KP-W122, C007KP-W123,C007KP-W162 , C007L-W122, C007L-W162, C007L-U122
Self-installation : Y
CHP
CY
[2 IN 1]Pneumatic Hemming / Tubular Elastic Tape hemming With Left Edge Trimmer
C007KP-W822
Self-installation : N
CL
CLA
TAPE BINDING
1. Pulls the fabric and elastic after sewing and makes sewing fast, flat
and smooth without wrinkles.
2.The attachment includes both CL(CL19+CL53) and CLA(CL20+
CL52). CLA is flat type for normal material, and CL is serrated type
for elastic or lace, etc...
3.For fine-tuning purpose, the machine will be equipped with one rear
puller depending on actual demand, the other one will be placed in
the accessory box.
C007KP
Self-installation : N
CQ
TAPE BINDING
- For tape binding on openings of leg or neck of underwears, T-shirts, etc…
- If purchased machine with CQ device, FG device will also be included. If only CQ device were
purchased, no FG included. - Binder’s standard tape size is 1-3/8″ wide and finished size is 1/2″ wide in 3 folds. Please remark
if need another size when ordering, delivery and cost will be recalculated. - Ways to order the device:
| Model | CQ | FG | CQ Gauge Set | Binder |
|---|---|---|---|---|
| C007KP-W222-240/CQ | V | V | V | V |
| C007KP-W222-240 | X | X | V | X |
| C007KP-W222-240/CQ-P | V | V | V | X |
Available Model:
C007KP-W222
Self-installation : Y
CR
Right Hand Side Trimmer
Right hand side waste fabric trimming with waste suction device makes fabric edge aligned to seam and keeps the working area clean.
Available Model:
C007KP-W522, C007KP-W532, C007L-W532, C007L-U532
Self-installation : Y
CRL
LEFT HAND SIDE TRIMMER
Left hand side fabric trimming makes fabric edge aligned to seam.
Available Model:
C007KP-W812(A), C007KP-W822, C007L-W812,C007L-U812, C007L-W822
Self-installation : N
CW
FOUR-NEEDLE FLAT SEAMING
For flat seaming 2 pieces of fabrics on men’s briefs, fabric guide included.
Available Model:
C007KP-W922
Self-installation : Y
CX
PNEUMATIC ELASTIC INSERTING
For tubular elastic or lace waistband attaching on men’s or women’s briefs, with right hand side fabric trimming to increase sewing quality and efficiency.
Available Model:
C007KP-W532,C007L-W532,C007L-U532
Self-installation : Y
CZ
PNEUMATIC ELASTIC INSERTING
Attaching tubular elastic tape onto waistband, suitable for briefs. For using this device, CL and RLQ must be equipped together.
Available Model:
C007KP-W152
Self-installation : Y
CZP
Manual Elastic Inserting
Attaching tubular elastic tape onto waistband, suitable for briefs. For using this device, CL and RLQ must be equipped together.
Available Model:
C007KP-W152
Self-installation : Y
FA
SIDE ELECTRIC TAPE FEEDING
- With electronic switch to control the feeding length of tape, elastic or lace and make smooth sewing.
- Tape feeding is on the right side of control box.
Available Model:
C007KP/CQ, F007K/FQ, F007K/FFD,F007K/FFP, F007K/FSM,F007KD/FQ, F007KD/FFP
Self-installation : Y
FAC
FEC
FNC/FSC
FNC
FSC
F□C
Rear Cutter Series
| Operation Mode | Cutter Driven by | Sensor | Presser foot lifter | Controller | Function | |
|---|---|---|---|---|---|---|
| FAC | Knee | Air cylinder + mechanical Valve (Pneumatic) | - | - | - | Manual Cutting |
| FEC | Knee | Solenoid (Electric) | - | - | FE202-A Specific control box | Manual Cutting |
| FNC | Auto/ Knee | Air cylinder + Solenoid (Pneumatic) | V | V | GD60-4-FK-220 Driven by servo motor | The sensor checks the cloth edge. (Similar to ECA) |
| FSC | Auto/ Knee | Air cylinder + Solenoid (Pneumatic) | V | V | i70L-4-ME-220 Driven by servo motor, with Control Panel | Checking the cloth edge by sensor, and also the metering device controls the tape tension and the remained length. Applicable to bikini sewing. |
Available Model:
F007K/FQ, F007K/FE, F007K/SMK,F007K/STC, F007K/FR, F007K/FR/FQS
Self-installation : Y
FBP
BELT LOOP SEAMING
- Normal W122 type can be changed to FBP type with FBP-256 or FBP-264 for belt loop sewing.
- Different size binders and needles may be required depend on different fabric. Please refer to the below table and remark when ordering.
| Needle Guage | Finished Good | Folder No. | Fabric |
|---|---|---|---|
| 5.6mm | 9 mm | FBP01A | Suits for Men & Women |
| 5.6mm | 10mm | FBP01B | |
| 6.4mm | 12mm | FBP01C | Jeans |
Available Model:
F007K-U613, F007KD-U613
Self-installation : Y
FDC
COVERING SEAMING DEVICE
- Overturned seam covering for medium to heavy fabric after 3 or 4 thread plain seaming.
- Suitable for neck openings, sleeve, cuff or bottom of sportswear, T-shirt,etc… With fabric guide and special presser foot makeing sewing easy and more efficient.
Available Model:
F007K-W322, F007KD-W322
Self-installation : Y
FDE
COVERING SEAMING
- Overturned seam covering for medium to heavy fabric after 3 or 4 thread plain seaming.
- Suitable for neck openings, sleeve, cuff or bottom of sportswear, T-shirt,etc… With fabric guide and special presser foot makeing sewing easy and more efficient.
Available Model:
F007K-W322, F007KD-W322
Self-installation : Y
FE
ELECTRIC TYPE ELASTIC FEEDING
- Elastic feeding ensures even length and elasticity, controlled by electronic digital control box.
- Maximum feeding width of elastic is 2-1/2″.
Available Model:
F007K-W522, C007KP-W522
Self-installation : Y
FFC
MECHANIC TYPE ELASTIC FEEDING
- Elastic feeding ensures even length and elasticity controlled by gear set.
- Maximum feeding width of elastic is 2-1/2″.
Available Model:
F007K-W522, C007KP-W522
Self-installation : N
FFD
MECHANIC TYPE ELASTIC FEEDING & BINDING
- Elastic feeding ensures even length and elasticity controlled by gear set with elastic tape side-motion controller for sewing the beginning and ending of elastic tape onto waistband, leg opening of briefs, etc…
- Maximum width of elastic is 1/8″ to 1/4″.
Available Model:
F007K-W222
Self-installation : Y
FFP
MECHANIC TYPE ELASTIC FEEDING & BINDING(LEAF SPRING)
- Elastic feeding ensures even length and elasticity controlled by leaf spring with elastic tape side-motion controller for sewing the beginning and ending of elastic tape onto waistband, leg opening of briefs, etc…
- Maximum width of elastic is 1/8″ to 1/4″.
Available Model:
F007K-W222, F007KD-W222
Self-installation : Y
FH
Lower Fixed Tape Holder
Holds tape or elastic tape under the table
Available Model:
C007L/CFC, C007KP/CFC
Self-installation : Y
FHA
HEMMING DEVICE
Suitable for the bottom hemming of T-shirt, underwear, cuff of children’s garment,etc… Able to adjust the width of hemming set to meet different demands, easy operation.
Available Model:
F007K-W121, F007K-W122, F007K-W123, F007K-W162, F007KD-W121, F007KD-W122, F007KD-W123, F007KD-W162
Self-installation : Y
FL
REAR PULLER
Suitable for light to medium fabric, such as bedsheets, quilts, towels etc. With one set of adjustable bottom hemming device, FHA(K). (not suitable for the hard and slip fabric which is much heavy)
Available Model:
F007K-W121/FHA, F007K-W122/FHA, F007K-W123/FHA,F007K-W162/FHA, F007K-W222/FQ,F007KD-W121/FHA, F007KD-W122/FHA, F007KD-W123/FHA,F007KD-W162/FHA, F007KD-W222/FQ
Self-installation : Y
FP
CRINKLE SEAMING
To sew a decorative convex stripe on sportswear, jeans or other clothes, can also add extra stripe inside convex to increase the effects of convexity and decoration.
Available Model:
F007K-U122-232, F007KD-U122-232
Self-installation : Y
FQ
TAPE BINDING
For tape binding on openings of leg or neck of underwear,T-shirt etc.
- For tape binding on openings of leg or underwear,T-shirt,etc…
- If purchased machine with FQ, we will also attach FG. If purchase FQ device only, no FGattached.
- Binder’s standard opening size is 1-3/8″ wide and finished size is 1/2″ wide in 3 folds.Pleaseremark if need another size when ordering, delivery date and cost will be re-calculated.
- Ways to order the device:
| Model | FQ | FG | FQ Gauge Set | Binder |
|---|---|---|---|---|
| F007KD-W222-240/FQ | V | V | V | V |
| F007KD-W222- 240 | X | X | V | X |
| F007KD-W222-240/FQP | V | V | V | X |
Available Model:
F007K-W222, F007KD-W222
Self-installation : Y
FR
RIGHT HAND SIDE TRIMMER
Right hand side waste fabric trimming, ensures better sewing quality.
Available Model:
F007K-W522
Self-installation : N
FSM
ORNAMENTAL TAPE BINDING
Suitable for ornamental tape binding of neck band, bottom or cuff of T-shirt, shirt, etc… Four sets of cam create hundreds of patterns.
Available Model:
F007K-W222, F007KD-W222
Self-installation : N
FSP
DOUBLE LOOPER TAPE BINDING
| Presser Foot Code | Tape Width | Finish Width | Applicable Model |
|---|---|---|---|
| P5118 (binder included) | 25mm | 12mm | F007K(D)-U712A |
| P5117 (binder included) | 21mm | 10mm | F007K(D)-U712 |
Available Model:
F007K-U712, F007KD-U712
Self-installation : Y
FSR
LAP SEAMING
Differential ratio of left and right feed dog can be adjusted separately for lap seaming to ensure symmetrical length to both left and right fabric. Applicable to trousers, casual pants and jean, etc…
Available Model:
F007K-U712, F007KD-U712
Self-installation : N
FW
FWP
FLATSEAMER
For flat seaming 2 pieces of fabric, equipped with fabric guide for easy operation.
FWP: Folder(B417R) is optional, for tape attaching.
Avialable Model:
F007K-W922, F007KD-W922
Self-installation : N
FY
POCKET LINING SEAMING
This is a 3 needles 3 loopers machine, and special for seaming the shell fabric and lining of pocket in trousers or working pants in simple operation to increase sewing quality and efficiency.
Available Model:
F007K-W722, F007KD-W722
Self-installation : N
LFA
ELECTRIC TYPE UPPER TAPE FEEDING DEVICE
Elastic type is fed by electric motor to achieve zero tension. Elastic tape length can be easily adjusted to expect length to ensure elasticity consistency.
Voltage, 110V(Part NO. LF290-A1) / 220V(Part NO. LF290-A2)
applicable model:
C007KP/FE, C007KP/FFC, C007KP/CR/FE, C007KP/CR/FFC, F007K/FE, F007K/FFC,F007K/FFD, F007K/FFP, F007K/FSP, F007K/FBP, F007K/FWP, F007K/FR/FE, F007K/FR/FFC, F007KD/FE, F007KD/FFP, F007KD/FSP, F007KD/FBP, F007KD/FWP
Self-installation : Y
LF290
Untangline Wheel
An optional device to be equipped with LFA (tape feeding device). Untangling the elastic tape by reverse rotation wheel is a pre-feeding process.
Voltage, 110V(Part NO. LF290-A1) / 220V(Part NO. LF290-A2)
Available Model:
MODEL w/LFA
Self-installation : Y
LS-A
UPPER TAPE HOLDER
For top feeding tape or elastic.
Available Model:
C007KP/FE, C007KP/FFC, C007KP/CR/FE, C007KP/CR/FFC, F007K/FE, F007K/FFC,F007K/FFD, F007K/FFP, F007K/FSP, F007K/FBP, F007K/FWP, F007K/FR/FE, F007K/FR/FFC, F007KD/FE, F007KD/FFP, F007KD/FSP, F007KD/FBP, F007KD/FWP
Self-installation : Y
PCC
OVERLOCK-SEAM COVERING (FOLD-DOWN TYPE)
- Overturned seam covering for medium to heavy fabric after 4 thread plain seaming.
- Suitable for neck openings, sleeve, cuff or bottom of sportswear, T-shirt…etc. With fabric guide and special presser foot, making sewing easy and more efficient.
Available Model:
S007K all models, S007KD all models
Self-installation : Y
PCE
OVERLOCK-SEAM COVERING (FLATTENING TYPE)
- Bulging seam covering for medium fabric after 3 thread plain seaming.
- Suitable for neck openings, sleeve, cuff or bottom of sportswear, T-shirt…etc,. With fabric guide and special presser foot, making sewing easy and more efficient.
Available Model:
S007K all models, S007KD all models
Self-installation : Y
PCH
BOTTOM HEMMING
Suitable for the bottom hemming of T-shirt, underwear, cuff of children’s garment…etc. Able to adjust the width of hemming set to fit demands, easy operation.
Available Model:
S007K all models, S007KD all models
Self-installation : Y
RL
TUBULAR EXTENDING ROLLER (LONG TYPE)
Especially used to assist with tubular cloth sewing.
Available model:
C007KP/CY, C007L
Self-installation : Y
RLP1
TUBULAR EXTENDING ROLLER (SHORT + CONE TYPE)
Especially used to assist with tubular cloth sewing.
Available Model:
C007K/CX , C007KD/CX
Self-installation : Y
RLQ
TUBULAR EXTENDING ROLLER
Especially used to assist with tubular cloth sewing.
Avialiable Model:
C007KP/CZ
Self-installation : Y
SMK
Electric Metering type tape feeding
| SMK1 | – | □ | – | □ | |||||||||
| | | | | ||||||||||||
|
|
||||||||||||
Available Model:
C007KP/CR, F007/CR
Self-installation : Y
SRL
LEFT HAND SIDE TRIMMER (FOR SMALL CYLINDER BED)
Especially used to assist with tubular cloth sewing.
Avialiable Model:
S007KD-W815
Self-installation : N
STC
Tension sensor type tape feeding
| STC1 | – | □ | – | □ | ||||||||
| | | | | |||||||||||
|
|
|||||||||||
Available Model:
C007K-W512, C007K/CR, F007-W512, F007/CR
Self-installation : Y
Top Trimmer
Bottom Trimmer
Thread Gripping
Thread Blowing
UT
PNEUMATIC AUTOMATIC TOP & UNDER THREAD TRIMMER
| Model | Code | Function | Drive | ||||
| Top Trimmer | Bottom Trimmer | Thread Gripping | Thread Blowing | Pneumatic | Electronical | ||
| F007K | UTG | V | V | * | V | ||
| UTH | V | Optional | V | ||||
| UTJ | V | V | V | ||||
| UTK | V | V | |||||
| C007KP C007L | UTP | V | V | * | V | ||
| UTQ | V | Optional | V | ||||
| UTR | V | V | V | ||||
| UTS | V | V | |||||
| S007K | UTT | V | V | * | V | ||
| UTU | V | Optional | V | ||||
| UTX | V | V | V | ||||
| UTY | V | V | |||||
*Thread blowing device is included in the accessory box. If the coverstich thread is not required, users may install blowing device instead of upper thread trimmer.
DC
Lower main shaft type Direct-drive servo motor
| Model | Motor Series | Certification | Version | Funtion |
| DFK：F007K DCK：C007KP DCL：C007L DSK：S007K | H：H-Series motor U：U-Series motor | none：CE Certification D：Brazil Certification | 1：first version | ０：Simple type (needle position function) １： Pneumatic, Multi-functional ２： Electric, Multi-functional |
| Direct drive electric control box set | Accessories list | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| UTG | UTH | UTJ | UTK | FSC | UTP | UTQ | UTR | UTS | CAR | CR | CRL | UTT | UTU | UTX | UTY | SAR | CAF | ||
| F007K | DFKH③④-1 | ● | ● | ● | ● | ||||||||||||||
| DFKH③④-2 | ● | ● | |||||||||||||||||
| C007KP | DCKH③④-1 | ● | ● | ● | ● | ● | ● | ||||||||||||
| DCKH③④-2 | ● | ● | |||||||||||||||||
| C007L | DCLH③④-1 | ● | ● | ● | ● | ● | |||||||||||||
| DCLH③④-2 | ● | ● | |||||||||||||||||
| S007K | DSKH③④-1 | ● | ● | ● | ● | ||||||||||||||
| DSKH③④-2 | ● | ● | |||||||||||||||||
| U007 | DUKH③④-1 | ● | ● | ||||||||||||||||
| DUKH③④-2 | ● | ● | |||||||||||||||||
| F007K | DFKU③④-0 | ||||||||||||||||||
| DFKU③④-1 | ● | ● | ● | ||||||||||||||||
| DFKU③④-2 | ● | ● | |||||||||||||||||
| C007KP | DCKU③④-0 | ||||||||||||||||||
| DCKU③④-1 | ● | ● | ● | ||||||||||||||||
| DCKU③④-2 | ● | ● | |||||||||||||||||
| C007L | DCLU③④-0 | ||||||||||||||||||
| S007K | DSKU③④-0 | ||||||||||||||||||
