DOUBLE CHAINSTITCH

FBQ

BELT-LOOP SEAMING (WITH RIGHT & LEFT FABRIC TRIMMER)

This machine is equipped with an adjustable fabric trimmer to cut excess fabric edge neatly, and seaming to belt loops for saving cost and increase efficiency.

AVAILABLE MODELFINISHED SIZEBINDER NO.APPLICATION
HF008-02056/FBQ9mmFBQ14ATrousers
10mmFBQ14B
HF008-02064/FBQ12mmFBQ14CJeans
Self-installation : Y

FH

LOWER FIXED TAPE HOLDER

Holds tape or elastic tape under the table.

Availabel model :
VC008(A)/VWL, VC008(A)/VWLB, VC008(A)/VWLC, VC008(A)/VSF
HF008A/HPR

Self-installation : Y

HHD

LAP SEAMING

To lap seaming on light to heavy weight fabric such as workwear cloth or jeans, etc…
Available Model
Finished Size
Binder No.
02064/HHD
03064/HHD
1/4″
light
B511
medium
 B511P
heavy
 B511Q
Self-installation : Y

HPR

TAPE BINDING OF WAISTBAND

For tape binding on waistband of workwer pants, jeans, etc…  Different binders for various seam, please refer to the table below.

Finished SizeFor Continuous StripsFor Arched TypeSide FeedingFront Feeding
1" (25mm)---B530
1- 1/8" (29mm)---B530P
1- 1/4" (32mm)B516B518B519B530Q
1- 3/8" (36mm)B516PB518PB519PB530R
1- 1/2" (38mm)B516QB518QB519QB530S
1- 5/8" (42mm)B516RB518RB519RB530T
1- 3/4" (45mm)B516SB518SB519SB530U
Seam Type
Self-installation : Y

HTF

LAP SEAMING

To lap seaming on medium to extra heavy material such as workwear or jeans, etc…

Self-installation : Y

HWL(P)

REAR PULLER

Smooths the sewing process,and no shirr. The 72mm distance from the needle helps to stabilize the fabric during sewing process.

Available Model:
HF008A

Self-installation : N

JD

SKIP STITCH DEVICE

Control freely to avoid stitches sewed on un-wanted working area.

Available Model:
VC008(A), HF008A

Self-installation : N

LSA

UPPER FIXED TAPE HOLDER

Holds tape or elastic tape in front.

Available Model:
VC008(B)/VPL, VC008(B)/VSF

Self-installation : Y

RL

TUBULAR EXTENDING ROLLER

Especially used to assist with tubular cloth sewing.

Available Model:
VC008(B)/VPL, VC008(B)/VSF

Self-installation : Y

VAD

PNEUMATIC PRESSER FOOT LIFTER

Pneumatic presser foot lifer is used to improve operation efficiency.

Remark:

  1. Compressor capability needed.
  2. Servo motor needed.

Available Model:
VC008(A), VC008(B)

Self-installation : Y

VAR

CONDENSE STITCHING DEVICE

Reinforce the stitches at the beginning and end of sewing, to enhance sewing sturdiness and
quality.

Available Model:
VC008(A), VC008(B)

Self-installation : Y

VCE

TUBULAR ELASTIC INSERTING AND ATTACHING

Tubular elastic inserting on sports wear or man’s underwear, two types of sewing functions are available:

  1. To attach tubular seamless elastic waistband.
  2. To cover sewing on elastic after overlock seaming.

Available Model:
VC008(A), VC008(B)

Self-installation : Y

VCL(P)

REAR PULLER

Smooths the sewing process, and no shirr. The 72 mm distance from the needle helps to stabilize ther fabric during sewing process.

Remark:
Please check the type of pullers (flat or serrated) used for different machines from ther table below. If you would like to order different pullers standard, please remark when odering other than.

RollerFlatGear
UpperVCL16PVCL37P(27T)
LowerVCL28VCL33P(16T)
VC008-04xxxPs
VC008-04xxxP/VCEs
VC008-02xxxP/VMRs
VC008-04xxxP/VSFs
VC008-04xxxP/VWLs
VC008-06xxxP/VPLs
VC008-12xxxPs
VC008-12xxxP/VCEs
VC008-12xxxP/VPQs
VC008-12xxxP/VPTs
VC008-12xxxP/VWLs
VC008-12xxxP/VPQ-Ks
VC008-12xxxP/VSMVCL16D
VC008-12xxxP/VSQVCL16D

VCL Roller List
TypeFlat TypeGear TypeKnurling
MaterialPU (Black)Rubber (Black)POM (White)Steel
Length80mm80mm80mm78mm
Upper CoverVCL39RVCL39RVCL39RVCL39R
UpperVCL16PVCL16RVCL08P(22T) HeavyVCL08N (22T)
VCL37P(27T) Medium
*VCL16D
(for VSM,VSQ)
VCL60(44T) Light
VCL63(54T) Fine
LowerVCL28VCL28RVCL33(14T) HeavyVCN33N(22T)
VCL33P(16T) Medium
VCL61(28T) Light
VCL64(32T) Fine
Puller Set Application
Flat typePUFor common materials, eg: woven cotton fabric.
RubberFor tap attaching or slippery materials, eg: woven silk fabric.
Gear typeBig-teeth POMFor elastic band sewing, big gathering
Fine-teeth POMFor elastic band sewing, small gathering
Knurling Steel rollerFor jeans and heavy material

Available Model:
VC008(B)

Self-installation : N

VMR

RUFFLING

Decorative sewing on curtain and bed sheet or various ruffling patterns on table cloth or indoor decoration which controlled by cams.

Remark:

  1. Maximum 7-8mm space for shirring.
  2. Six cams as listed on V15.

Available Model:
VC008(A)-02064P

Self-installation : N

VPL

TAPE ATTACHING

Decorative tape for shirt-fronting, sports-wear, waist band, etc…

Remark:

  1. Binder and finished goods speifications as listed in the table below.
  2. Type size can be adjusted in multiples of  3/16” to 1/4”.



ModelFinished
Size(mm)
XYZNeedle GaugePresser Foot
VC008-06048P8B417PB417APB417APB417UP9412DA
9B417QB417QB417QP9412D
VC008-06064P10B417RB417RB417RB417UP9512DA
12B417SB417SB417SP9512D
16B417UB417UB417UB417UP9512B
VC008-12064P16B417UB417UB417UB417UP9712D

Available Model:
VC008(B)-06048P,VC008(B)-06064P

Self-installation : Y

VPQ

ELASTIC THREAD SHIRRING

Suitable for sewing ornamental shirring on ladies’ blouses. Suggested to use elastic therad for lower looper.

Available Model:
VC008(A)-12048P, VC008(A)-12064P

Self-installation : Y

VPQ-K

ELASTIC THREAD SHIRRING

Suitable for sewing ornamental shirring on ladies’ blouses.

  1. Suggested to use elastic thread for lower looper.
  2. The added VWL set will further stabilize the tension of the elastic thread and make sewing process more smoothly, also can avoid stitch skipping.
  3. Holds the elastic thread under the table to make sewing process more smoothly.
  4. Multifunction device can be adjusted to VWL or VPQ.

Available Model:
VC008(A)-12048P, VC008(A)-12064P

Self-installation : Y

VPS

ELASTIC THREAD SHIRRING

Suitable for sewing ornamental shirring on ladies’ blouses, swimsuits, pillowcase, children’s shirts. Needle uses elastic thread and looper without any thread. It’s 101 sewing type.

Available Model:
VC008(A)-12048P, VC008(A)-12064P

Self-installation : Y

VPT/VPTA

TUCKING

Using various folders for different side shirring patterns, suitable for shirts, woman’s dress, children’s shirts, nylon pants.

Remark:
When installing VPT device on standard machine, position of VA05 and VA06 folder need to be tapped first.

VPT:Visible Fold Seaming
VPTA:Blind Fold Seaming

Available Model:
VC008(A)-12048P, VC008(A)-12064P

Self-installation : Y

VSC

ELASTIC THREAD SHIRRING SEWING

Elastic thread is straight, not looped, which is fixed by needle thread and looper thread. The finish is thinner than VPQ and  the shirring becomers flat as it is pulled extensively.

Applicable Model:
VC008(A)-12048P, VC008(A)-12064P

Self-installation : N

VSF

SHIRT-FRONTING

Using 4 or 2 needle and special folder for shirt-fronting, only one sewing process is required. Size of folder as listed in the table below.

Code \ SpecFinished SizeTape SizeNeedle GaugeModel
B5291-3/8''2-3/8''1/4 - 3/4 - 1/4''VC008-0464-191P
B529P1-1/2''2-1/2''3/16 - 1 - 3/16''VC008-0448-254P
B529Q1-5/8''2-5/8''1/4 - 1 - 1/4''VC008-0464-254P

Applicable Model:
VC008(B)-0448-254P, VC008(B)-0464-191P,VC008(B)-0464-254P

Self-installation : Y

VSM

DECORATIVE SEWING DEVICE

Using sixteen different cams of variation for different sewing, suitable for decorative sewing on high quality dress, curtain, bedcover, table cloth or indoor decoration.

Available Model:
VC008(A)-12048P, VC008(A)-12064P

Self-installation : N

VSQ

DECORATIVE SEWING DEVICE WITH ELASTIC THEAD SHIRRING

Using sixteen different cams of variation for different sewing, suitable for decorative sewing on high quality dress,curtain, bedcover, table cloth or indoor decoration.

Available Model:
VC008(A)-12048P, VC008(A)-12064P

Self-installation : Y

VSSM

DECORATIVE SEWING

To use sixteen different cams of variation for different sewing, suitable for decorative sewing on high quality dresses, curtains, bed sheets and tablecloths.

Applicable Model:
VC008(A)-12048P, VC008(A)-12064P

Self-installation : N

VUT

PNEUMATIC AUTOMATIC THERAD TRIMMER

Pneumatic automatic thread trimmer increases operation efficiency and saves the cost.

Available Model:
VC008(B)-04064P, VC008(B)-04085P, VC008(B)-04095P, VC008(B)-04106P, VC008(B)-04127P, VC008(A)-12050P

Self-installation : N

VWL/VWLB/VWLC

FRONT ELASTIC FEEDING

Length of elastic type can be easily adjusted by elastic feeding device, suitable for sports pants and casual paints. Roller maintains the tension of elastic thread and quality during sewing process.
Remark:VWL with binder B413
VWLB with binder B411 and extending roller
VWLC with VCE fabric guide

Available Model:
VC008(A)-04064P, VC008(A)-04085P, VC008(A)-04095P,
VC008(A)-04106P, VC008(A)-04127P, VC008(A)-12048P,
VC008(A)-12064P

Self-installation : Y
