FFT TOP FEEDING FUNCTION
Choose model
ESPECIFICACIÓN
| ① Modelo | ④ Funciones | ⑦ Calibre de aguja |
| ② Series | ⑤ Placa de aguja | ⑧ Dispositivos |
| ③ Covering Types | ⑥ Needle Numbers | ⑨Motor U：U Series H：H Series |
|
|
|
|
|
|
|
|
| |
|---|---|---|---|---|---|---|---|---|---|
| C007KP-W122-⑥⑦/FFT/CH/⑨ | 2 | 4 | 4.0/4.8 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
| C007KP-W122-⑥⑦/FFT/CH/⑨ | 3 | 5 | 5.6/6.4 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
| C007KP-W131-⑥⑦/FFT/CH/⑨ | 2 | 4 | 4.0/4.8 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
| C007KP-W131-⑥⑦/FFT/CH/⑨ | 3 | 5 | 5.6/6.4 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
| C007KP-W132-⑥⑦/FFT/CH/⑨ | 2 | 4 | 4.0/4.8 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
| C007KP-W132-⑥⑦/FFT/CH/⑨ | 3 | 5 | 5.6/6.4 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
| C007KP-W812A-⑥⑦/FFT/CRL/⑨ | 2 | 4 | 4.0/4.8 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
| C007KP-W812A-⑥⑦/FFT/CRL/⑨ | 3 | 5 | 5.6/6.4 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
| C007KP-U812A-⑥⑦/FFT/CRL/⑨ | 2 | 4 | 4.0/4.8 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
| C007KP-U812A-⑥⑦/FFT/CRL/⑨ | 3 | 5 | 5.6/6.4 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
| C007KP-W812A-⑥⑦/FFT/CRL/CW/⑨ | 4 | 6 | 5.6/ 6.0/ 6.4 | 1.4~3.6 | 0.3~2.9 | 1~5.5 | 5 | H / U | 4500 |
FFT TOP FEEDING FUNCTION
Back and forth moving feed dog is designed by patent and improved mechanism. The effective feeding stroke is bigger, and fabric feeding is more stable.
Recommended for thin fabrics W812
|
OPTIONAL DEVICE |
|||
|
UTP , UTR |
