Specification

General

Optional

odel name
 Bartacking Belt-loop Attaching Button Sewing
LKS-1900AN-SS
 LKS-1900AN-HS
 LKS-1900AN-FS
 LKS-1902AN-SS
 LKS-1902AN-HS
 LKS-1903AN-SS
Application Standard For heavy-weight materials For foundation Standard For heavy-weight materials Standard
Max.sewing speed 3,200sti/min* 3,000sti/min* 2,700sti/min*
Sewing area 30mm(L)X40mm(W) Button size: Round-shaped, flat button Size :Φ8~Φ32mm (standard Φ8~Φ20mm)
Stitch Iength 0.1~10mm(0.1mm step)
Needle bar stroke 41.2mm 45.7mm
Lift of the work clamp foot Standard 14mm(17mm when the reverse-rotation needle-up function) MAX. 13mm
Auto-lifter Provided as standard (stepping motor type)
Needle thread tension Active tension (electronic thread tension control system)
Needle DPX5(#14) DPX7(#21) DPX5(#11) DPX5(#14) DPX7(#21) DPX17(#14)
Hook standard shuttle hook
Number of stitches thatcan be stored in memory Max. 20,000 stitches
Number of standard patterns 50 patterns 17,18(19,20,21,22*)*This device has been factory-set to”invoking prohibited”status at the time of delivery. 50 patterns
Number of data that can be input 200 patterns (for up to 150 patterns,sewing data can be added.)
Enlarging/Reducing facility 20~200%(1% step), Pattern enlargement/reduction can be done by increasing/ decreasing the stitch length
Memory media EEP-ROM，EP-ROM
Bobbin thread counter Provided as standard(up/down method)
Lubrication Hook: minute-quantity lubrication
Lubricating oil ISO VG32
Sewing machine motor Compact AC servo motor(direct-drive system)
Power consumption 450VA 530VA
Weight Machine head (include motor)42kg，Control box 16.5kg Machine head (include motor)47.3kg，Control box 11.3kg

Remark:
*sti/min stands for “Stitches per Minute”
*Compact Flash TM or CFA spcification compatible media.
*Compact Flash TM is a registered trademark of SanDisk Corporation, U.S.A.

Remark:
*sti/min stands for “Stitches per Minute”
*Compact Flash TM or CFA spcification compatible media.
*Compact Flash TM is a registered trademark of SanDisk Corporation, U.S.A.

LKS1900AN
Computer-Controlled Bartacking Machine

LKS1902AN
Computer-controlled Bartacking Machine (For Belt-Loop Attaching)

LKS1903AN
Computer-controlled Lockstitch Button Sewing Machine
